D-Link DES-105 kovový 5-port 10/100 Desktop Switch
Skladem 20 ks Náš kód: 51202620 EAN: 790069368189 P/N: DES-105/E
Výrobce: D-LINK Záruka: 60 měsíců
D-Link DES-105 5-port Fast Ethernet Switch PŘEHLED Přepínač D-Link DES-105 Fast Ethernet poskytuje pro SOHO a SMB cenově výhodný způsob, jak vytvořit malou síť a připojit počítače, bezdrátové přístupové body, IP kamery, síťové tiskárny a…
Parametry - D-Link DES-105 kovový 5-port 10/100 Desktop Switch
D-Link DES-105 5-port Fast Ethernet Switch
OVERVIEW
D-Link’s DES-105 Fast Ethernet switch provides a cost-effective way for SOHO and SMB to create a small network and connect computers, wireless Access Points, IP cameras, network printers and other Ethernet devices quickly and easily without complicated configurations. This switch comes with 5 Fast Ethernet ports with an auto-sensing function to detect the maximum speed of the connected devices, allowing you to run your network with the best possible performance. Its fanless design makes this switch completely silent, ideal for offices, libraries or meeting rooms.
FEATURES
• Plug and Play operation
• 5 Fast Ethernet ports
• Non-blocking architecture: simultaneous full speed on all ports
• Fanless, silent operation to fit in any environment
• Quality of Service (QoS) queues for traffic prioritisation
• Solidly built with metal housing
• D-Link Green™ technology, saves energy and increases the product’s lifespan
SPECIFICATIONS
Standards
• IEEE 802.3 10BASE-T Ethernet
• IEEE 802.3u 100BASE-TX Fast Ethernet
• ANSI/IEEE 802.3 NWay auto-negotiation
• IEEE 802.3x flow control
• IEEE 802.3az Energy Efficient Ethernet (EEE)
Layer2 Features
• MAC address table: 2K
• Auto MDI/MDIX crossover for all ports
• Store-and-forward switching scheme
• Full/half-duplex for Ethernet/Fast Ethernet speeds
• Jumbo Frames: 2047 Bytes
Switching fabric
• 1.0 Gbps
Data Transfer Rates
• Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex)
• Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex)
Packet Filtering/Forwarding Rates
• Ethernet: 14,880 pps per port
• Fast Ethernet: 148,800 pps per port
RAM Buffer
• 384 KB
LED Indicators
• Per port: Link/Activity
• Per device: Power
Quality of Service (QoS)
• Supports 802.1p QoS
• 2 Queues, Strict Mode
Green features
• Energy Efficient Ethernet (EEE) standard
• RoHS compliant
Power
• External 5 V/1 A Level “V” Power Adapter
Power Consumption (DC input)
• Standby: 0.35 W.
• Maximum: 1.9 W.
MTBF
• 495,709 hours
Temperature
• Operating: 0 to 50 °C
• Storage: -10 to 70 °C
Humidity
• Operating: 10% to 90% RH non-condensing
• Storage: 5% to 90% RH non-condensing
Dimensions (W x D x H)
• 100 x 98 x 28 mm
Certifications
• FCC Class B
• ICES-003 Class B
• CE Class B
• C-Tick Class B
• VCCI Class B
• cUL
• CB
