ZYXEL NWA220AX-6E,Standalone/NebulaFlex Outdoor WIFI

Parametry - ZYXEL NWA220AX-6E,Standalone/NebulaFlex Outdoor WIFI

Description: 802.11ax (WiFi 6E) Dual-Radio Unified Pro Access Point Wireless Standard: IEEE 802.11 ax/ac/n/g/b/a MIMO: MU-MIMO Wireless speed : *2.4GHz: 575 Mbps *5GHz: 4800 Mbps *6GHz: 4800 Mbps Frequency band: *2.4 GHz *USA (FCC): 2.412 to 2.462 GHz *Europe (ETSI): 2.412 to 2.472 GHz *5 GHz *USA (FCC): 5.15 to 5.35 GHz; 5.470 to 5.850 GHz *European (ETSI): 5.15 to 5.35 GHz; 5.470 to 5.725 GHz *6 GHz *USA (FCC): 5.925 to 6.425 GHz; 6.525 to 7.125 GHz *European (ETSI): 5.925 to 6.425 GHz Bandwidth: 20-, 40-,80- and 160-MHz Conducted typical transmit output power: *US (2.4GHz/5GHz) or +/6GHz): 24/28/24dBm *EU (2.4GHz/5GHz) or +/6GHz): 18/25/19dBm RF Design Antenna type: 4x4 + 2x2 Dual-optimized Antenna Antenna gain: *2.4 GHz: Peak Gain 3dBi *5 GHz: Peak Gain 5dBi *6 GHz: Peak Gain 6dBi Minimum Receive sensitivity: Min. Rx sensitivity up to -101 dBm WLAN feature Band Steering: Yes WDS/Mesh: Yes Fast roaming: Pre-authentication, PMK caching and 802.11r/k/v DCS: Yes Load balancing : Yes Advanced Cellular Coexistence: Yes Security *Encryption *WEP *WPA *WPA2-PSK *WPA3 Authentication: *WPA *WPA2 *WPA3-Enterprise *EAP *IEEE 802.1X *RADIUS authentication Access management: *L2-isolation *MAC filtering *Rogue AP detection Networking IPv6: Yes VLANs: Yes WMM: Yes U-APSD: Yes Management Operating mode: *Nebula Cloud managed *Controller-managed *Standalone ZON Utility: *Discovery of Zyxel switches, APs and gateways *Centralized and batch configurations *IP configuration *IP renew *Device reboot *Device locating *Web GUI access *Firmware upgrade *Password configuration Zyxel Wireless Optimizer: *WiFi AP planning *WiFi coverage detection *Wireless health management Web UI/CLI: Yes SNMP: Yes Physical Specifications Item Dimensions (WxDxH)(mm/in.): 180 x 180 x 42 mm / 7.09 x 7.09 x 1.65 Weight (g/lb.): 650g/1.43lb Packing Dimensions (WxDxH)(mm/in.): 197 x 190 x 60 mm / 7.76 x 7.48 x 2.36 Weight (g/lb.): 780g/1.72lb Included accessories: *Mount plate *Mounting screws MTBF (hr): 711,333 Physical Interfaces Ethernet port: *1 x 1/2.5Gbps LAN *1 x 1Gbps LAN Power: *PoE (802.3)at: power draw 21 W *DC input : 12 VDC 2A PoE Modes: *IEEE802.3af: No Wireless *IEEE802.3at: Unrestricted *IEEE802.3bt: Unrestricted
