TP-LINK

TP-Link EAP115 N300 WiFi Ceiling/Wall Mount AP Omada SDN

300Mbps Wireless N Ceiling Mount Access Point: EAP115 300Mbps Wireless N Ceiling Mount Access Point, Qualcomm, 300Mbps at 2.4GHz, 802.11b/g/n, 1 10/100Mbps… Číst více

Kód: 51722446 P/N: EAP115 EAN: 6935364096939
Ano In (vstup) 300 Mbit/s
P/N: EAP115 EAN: 6935364096939
Skladem · Odešleme zítra
859 Kč s DPH
710 Kč bez DPH
Doprava zdarma od 5 000 Kč
•
Záruka 60 měsíců
859 Kč s DPH

300Mbps Wireless N Ceiling Mount Access Point: EAP115

300Mbps Wireless N Ceiling Mount Access Point, Qualcomm, 300Mbps at 2.4GHz, 802.11b/g/n, 1 10/100Mbps LAN, 802.3af PoE Supported, Centralized Management, Load Balance, Rate Limit, Captive Portal, Cluster Mode, 2 Internal Antennas, Ceiling/Wall Mount

PŘEHLED

  • Free Auranet Controller Software enables administrators to easily manage hundreds of EAPs
  • The user-friendly Cluster Mode allows manage up to 24 (EAP115) without requiring any extra hardware or software
  • Supports Power over Ethernet (802.3af) for convenient and affordable installation
  • Simple mounting design for easy attachment to a wall or ceiling
  • Captive portal provides one convenient method of authentication for Wi-Fi guests
  • Enterprise class Wi-Fi security help to decrease network security threats
  • Multi-SSID divides multiple wireless networks for different user types

TECHNICKÁ SPECIFIKACE

Interface

  • Fast Ethernet (RJ-45) Port *1(Support IEEE802.3af PoE)

Button

  • Reset

Power Supply

  • PoE or external 12VDC/1.0A power supply

Power Consumption

  • 5W

Wireless Standards

  • IEEE 802.11n, IEEE 802.11g, IEEE 802.11b

Dimensions ( W x D x H )

  • 180*180*47.5mm

<b></b>

Antenna Type

  • Internal 2* 3dBi Omni

Mounting

  • Ceiling /Wall Mounting (Kits included)

Physical Security Lock

  • Kensington Lock Slot

Watch Dog

  • Yes

WIRELESS FEATURES

Wireless Standards

  • IEEE 802.11n, IEEE 802.11g, IEEE 802.11b

Frequency

  • 2.4-2.4835GHz

Signal Rate

  • 11n: Up to 300Mbps(dynamic)
  • 11g: Up to 54Mbps(dynamic)
  • 11b: Up to 11Mbps(dynamic)

Reception Sensitivity

  • 300M: -71dBm@10% PER
  • 150M: -75dBm@10% PER
  • 54M: -78dBm@10% PER
  • 11M: -93dBm@8% PER
  • 6M: -92dBm@10% PER
  • 1M: -96dBm@8% PER

Wireless Functions

  • Multiple SSIDs (Up to 8 SSIDs)
  • Enable/Disable Wireless Radio
  • Automatic Channel Assignment
  • Transmit Power Control (Adjust Transmit Power on dBm)
  • QoS(WMM)
  • Rate Limit
  • Reboot Schedule
  • Wireless Schedule
  • Wireless Statistics based on SSID/AP/Client

Wireless Security

  • Captive Portal Authentication
  • Access Control
  • Wireless Mac Address Filtering
  • Wireless Isolation Between Clients
  • SSID to VLAN Mapping
  • Rogue AP Detection
  • 802.1X Support
  • 64/128/152-bit WEP / WPA / WPA2-Enterprise,WPA-PSK / WPA2-PSK

Transmission Power

  • CE:
  • Auranet Controller Software
  • Yes

Cluster Mode

  • Yes

Email Alerts

  • Yes

LED ON/OFF Control

  • Yes

Management MAC Access Control

  • Yes

SNMP

  • v1,v2c

System Logging Local/Remote Syslog

  • Local/Remote Syslog

Telnet

  • Yes

Web-based Management

OTHERS

Certification

  • CE, FCC, RoHS

Package Contents

  • 300Mbps Wireless N Ceiling Mount Access Point EAP115
  • Power Adapter
  • Mounting Kits,
  • Installation Guide

System Requirements

  • Microsoft Windows 10/8/7/Vista/XP

Environment

  • Operating Temperature: 0°C~40°C
  • Storage Temperature: -40°C~70°C
  • Operating Humidity: 10%~90% non-condensing
  • Storage Humidity: 5%~90% non-condensing
Krátké představení Omada SDN:https://www.youtube.com/watch?v=Veb8-o8EE6U

* HTTP/HTTPS

Konektivita

LAN porty
Max rychlost Wi-Fi 300 Mbit/s
Antény Všesměrové
Wi-Fi 4 (802.11n)
WiFi 1 (802.11b)
WiFi 3 (802.11g)

Napájení

PoE In (vstup)
PoE výkon (W) Nevztahuje se
PoE Out standard Nepodporuje
PoE In standard 802.3at (max. 33,6W) - PoE+

Ostatní

Typ zařízení Acces point/Bridge
Použití Vnitřní
